Description

OPTICAL

LIGHT SOURCE : 120pcs 10w RGBW 4 in 1 LED
Beam angle : 20.4°, Spot angle: 37.5°
Vertical tilt angle : ±45°
Color temperature : 2500K-10000K
White color rendering index : RA≥70
Light source luminous flux : 35704 Lm
Illumination : 10630 Lux @ 5 meters
Average life of light source : 20000H





EFFECTS

Color mixing system : uniform RGBW color mixing system
Color macro : static effect macro and dynamic effect macro function
Dimming : Electronic dimming, providing four dimming curves
Strobe : 1-25Hz electronic strobe and random strobe







CONTROL

Control channel : 10CH (standard)
Control protocol : standard DMX512 protocol, RDM protocol
Data connection : three-core or five-core signal input/output





POWER

Input voltage : AC 100-240V 50/60Hz
Maximum power : 813W
Maximum lamp current : 8.13A/100V; 3.56A/220V





SIZE & WEIGHT

Product dimensions : 640×280×645mm
Net weight : 31.8kg





OTHERS

Protection level : IP66
Working environment : -10℃ ~ 45℃
Maximum lamp surface temperature : 75°C





Dimension drawing
Hanger picture

Fly case(optional)


Inventory code:

Lighting quantity on one flycase:2 in1

Flycase dimension:

N.W : kg/pcs

G.W with fly case: kg (2 in 1)

Light HookPower Cable

Safety RopesSignal cable
