Light Source / Power System

Voltage : AC100V~240V/50Hz~60Hz
Power : 270W
LED chip : 19pcs *10W , RGBW 4 in 1 LED Chip
LED Life span : 30% weaker after 20000h
Strobe : 1 ~30 times/ second electronic strobe and random strobe
Dimmer : 65536 class dimmer

Color / GOBO / Effects

Lens degree1 : 8 degree , facula angle : 10 degree (standard)
Lens degree2 : 22 degree, facula angle : 32 degree( selective)
Color sytem : RGBW marco color system

Control System

Pan/Tilt : Pan: 540°/2 seconds, Tilt : 180°/1.2 seconds
Control Mode : DMX512, RDM, Stand-alone Mode , Voice Control Mode,
                         Master-Slave Mode, Wireless DMX512
Channel : standard: 15 CH, simple : 9CH Extend 1: 23 CH, Extend 2 : 27 CH

Other functions

Display Menu :
1、 2.4 inches TFT touch screen, Chinese and English two version language
2、 display board can record device’s using time , show device’s
       temperature, channel date and software version
3、 Edit the procedure
Other Feature :
1、 Extend IP address function, each IP address Maximum can set 64 ID
2、 Support DMX signal priority identification, when lose the
       signal it would be turn into Black, default scene, Automatic
       function etc according to the setting
3、 software upgrade : upgrade software by XLT cable

Appearance Parameters

Outlooking : adopt ABS anti-fire plastic
Light Size : 322x242x345.5(mm)
Carton Size : 412x287x525(mm)
N.W : 8.5Kg     G.W : 11.1Kg
