Light Source / Power System

Voltage : AC100V~240V/50Hz~60Hz
Power : 264W
LED chip : 18pcs *10W ， RGBW 4 in 1 LED chip
LED life span : 30% weaker after 20000h
Lens : Aspheric lens

Color / GOBO / Effects

Lens angle : 1.5°
Facula angle : TX1810BEAM minimum 6°, Maximum 60°
Color rotation system : RGBW 4in 1 rotation , Marco color system
Strobe : 1~30 times/ second electronic strobe and random strobe
Dimmer : 65536 class dimmer

Control System

Control Mode : DMX512, RDM, Stand-alone mode ,Voice Control mode ,
                         Mater-Slave mode , Wireless DMX512.
Channel : Simple:11CH, Standard:17CH, Extended 1:21CH, Extended 2:25CH

Other functions

Display Menu :
1 、2.4 inches TFT touch screen , Chinese and English two version language.
2 、display board can record device’s using time , show device’s
       temperature, channel data and software version .
3 、Edit the procedure
Other feature :
1 、Extend IP address function , each IP address maximum can set 64 ID
2 、Support DMX signal priority identification, when lose the
       signal it would be turn into Black , default scene , Automatic
       function etc according to setting
3、 software upgrade : upgrade software by XRL cable

Appearance Parameters

Outlooking : adopt ABS anti-fire plastic
Light size : 322x242x336(mm)
Carton Size : 412x287x525(mm)
N.W : 8.5Kg
G.W : 11.1Kg
