Light Source / Power System

Voltage : AC100~240V (190-240V/4.5A; 100-125V/8.5A)
Power : 630W
Power factor : 0.982
Light source : 360W white light LED module
Color temperature : 6300k
Average lifespan : 20000h
Focus and lens : φ127 Optical lens with high precision，linear electronic adjustment
Strobe : 1-25 times/second (adjustable)
Dimmer : electronic dimmer,0-100% linear adjustment

Color / GOBO / Effects

Color wheel : 8 color+1 white,Bi-directional rotating rainbow effect
Color mixing system : Linear CMY+CTO color mixing system
Enhance CRI color rendering : Can increase to 91 the above
Fixed gobo wheel : φ138，9+1 white，Bi-direction flow water animation effect
Rotation gobo wheel : 7+1 white，Bi-direction flow water animation effect
Prism : 4prism+16 facet prism +prism combination
Frost : 1°and 10°Two-level frost and superposition effect
Zoom angle : 5°-40°

Control System

Control mode : DMX-512, RDM, Art-Net
Motors : 20 pcs super mute motor
Channel : Standard channel:27CH; Extension channel:33CH
Pan/ Tilt : Pan: 540°/ 2.7S，Tilt: 270°/ 2.1S
Pan/Tilt Resolution : 2.11°/1.05°
Software upgrading system : USB

Other functions

Display : 1、Display panel adopts 2.8 inch resistive color touch screen with good pressure sensitivity
2、Chinese and English languages can be switched freely，menu available to display 180°reversely
IP set : Built in battery, IP address could be set without electricity.
Features : 1、Input signal isolation: guarantees stable signal transmission without interference。
2、Advanced Art-Net function
Safety Devices : BIPOlar circuit breaker with thermal protection.
The vertical direction : The vertical direction of the use of hidden locking device,convenient transportation and maintenance.

Appearance Parameters

Structure : heat-proof plastic+module pressing alloy materials
IP rate : IP20
Light size : 510X300X731(mm)
N.W : 31.5Kg
A single carton size : 810×580×395(mm)
N.W : 31.5Kg        G.W : 35.5Kg
A single flight case size : 620X580X850(mm)
N.W : 31.5Kg        G.W : 64.5Kg
