Light Source / Power System

Voltage : AC100V~240V /50Hz~60Hz.
Power : 246W.
LED chip : 10W,RGBW 4 in 1 LED chip.
LED life : 30% weaker after 20000h.


Color / GOBO / Effects

Beam angle : Zoom function min.7°,max.55°.
Color : RGBW Color system, soft and no flicker. Single ring can be
            controlled separately,fast marco color system.
Strobe : 1~30 times/ second electronic strobe and random strobe.
Dimmer : 65536 class dimmer.


Control System

Pan/Tilt : Pan: 540° times /2.0 seconds Tilt: 180°/1.2 seconds.
Control Mode : DMX512, RDM, Stand-alone mode ,Voice Control
                         mode , Mater-Slave mode , Wireless DMX512.
Channel : Simple(10CH),Standard(16CH), Extended1(20CH), Extended2(24CH)


Other functions

Display Menu :
1、 2.4 inches TFT touch screen, Chinese and English two version language.
2、 Display board can record device’s using time , show device’s
       temperature, channel data and software version .
3、 Edit the procedure
Other feature :
1、 Extend IP address function , each IP address maximum can set 64 ID
2、 Support DMX signal priority identification, when lose the
       signal it would beturn into Black , default scene , Automatic
       function etc according to your set.
3、 Software upgrade : upgrade software by XRL cable.


Appearance Parameters

Outlooking : adopt ABS anti-fire plastic.
Light size : 322x242x336(mm)
Carton size : 412x287x525(mm)
N.W : 8.5Kg       G.W : 11.1Kg
