Light Source / Power System

Voltage : AC100-240V 50/60Hz
Power Consumption : 300W
Power input interface : PG Cable
DMX/RDM XLR In/Out : 3 pin (5 pin option)
Light source : 19pcs×15W White LED chip ((2550K +6400K)White LED
LED Power : 15W
LED QTY : 19pcs
Average lifespan : ≥50000h
Lumen : 6380 lm
Lens material : PMMA
Installation working angle : ±90°


Color / GOBO / Effects

Beam angle : 38°
Color mixing : Cold and warm white color mixing system, uniform color mixing without flicker
Dimmer : 16Bit, 0 to 100% linear dimmer
Super bright strobe : ensure fast flashing while maintaining light brightness
Strobe : 0.5-13 times/second
Ultra-high power stroboscopic effect : When the color temperature channel and dimming DMX reach the maximum 255, turning on the strobe function will release full power.


Control System

RDM : RDM signal two-way transmission
Menu control : Menus can show its temperature, channel data and software version.
Control Mode : DMX512、RDM
Channel model : 5CH (Standard)


Appearance Parameters

Outlooking : The fixture adopts a die-casting aluminum alloy split structure design, which has good heat dissipation performance.
IP rate : IP20
Accessory : bar door (optional), clamp (optional)
Light Size : 231×194×279(mm)
N.W : 3.4Kg
Carton Size : 220×220×255(mm)
G.W (Carton) : 3.8Kg
4 PCS carton size : 465×465×280(mm)
4 PCS N.W : 13.6Kg 4 PCS G.W(Carton) : 16.2Kg
