Description

Light Source System

Voltage : AC100-240V 50/60Hz
Power rating : 550W;
Lamp : OSRAM SIRUS HRI 420S
Light source power : 420W
Power in connector : standard is PG Power connector Neutrick Power con is selective
DMX and RDM data in/out : 3-pin or 5 pin XLR
Lamp CCT : 7700±300K
Average life span : 2500h(Normal),4000h(Eco)
CRI : 85±5
E-Ballast : Electronic Ballast
Luminous Flux : 20500lm
CCT Light output : 5700K



Optical System

Beam range : Beam Projection 2.3-12°,Spot Projection 9-36°,Wash Projection 15-53°
Output lens diameter : φ138mm
Fixture total lumen output : 12230 lm
Light output : 346763 lux @10m



Dynamic Effects

Colour Wheel : 13colours + open,Bi-direction rotation and rainbow effect
Rotating gobo wheel : 7 rotating Gobos+open,Bi-direction flow water animation effect
Static gobo wheel : 11 Gobos + open + 1 flame gobo , Bi-direction flow water animation effect
Animation gobo wheel : Aluminium animation wheel, Independent use or in combination with gobos, rotating in bi-direction and with variable speed
Prism : 8 facet round prism +6 facet round prism + linear CTO effect
Frost effect : adjustable wash effect angle
Focus : Motorized focus
Strobe : Pre-programmed random strobe & pulse effects(0.5-12Hz/second)
Dimmer : 0-100% linear adjustment



Movement

Pan movement : 540° Tilt movement : 270°
Pan / Tilt Resolution : 2.11°/1.05°
Movement control : Standard and Speed



Control And Programming

RDM : RDM two-way data transmission,Remote reset DMX address.
Display : The display panel adopts a 1.77-inch Colourful TFT screen
Intelligent control : Display board can record device’s using time , device’s temperature, channel data and software version .
Software upgrade : Upgrade with DMX
Control mode : DMX-512, RDM
Control channels : 21CH,24CH



Appearance Parameters

Product dimension : 390×273×643(mm)
Net weight : 22.5Kg
Packing dimension (carton) : 470×350×745(mm)
Gross weight (carton) : 26.2Kg
