Light Source / Power System

Voltage : AC100V-240V~/ 50-60Hz
Power : 410W,PF0.98
LED chip : TYANSHINE 19×20W White 3000K+6000K LED
Average life : 30000h
Optical system : High precision combination structure, high
permeable glass light rod +PMMA lens


Color / GOBO / Effects

Zoom angle : 7°~55°
Color temperature adjustable range : 3000~6000K
CRI : Ra≥90
Zoom system : Linear electric zoom
Strobe : 1-30Hz electronic strobe and random strobe
Dimmer : Electronic dimmer,provides four dimming options;


Control System

Pan/Tilt : Pan/Tilt Travel: 540°/210°
Pan/Tilt Fine: 2.11°/0.82°
Pan/Tilt Speed: 2.5S/1.0S
Control Mode : DMX512、RDM
Channel : Standard-13CH
Display : 2.4 inches LCD12864 display screen. With
      Chinese and English two version language.
Working mode : Silent mode;Standard mode; High Brightness mode
Intelligent control : Display board can record device’s
      using time , show device’s temperature, channel
      data and software version .


Other functions

Error alarm : Automatic alarming for fixture error
Software upgrade : Upgrade via DMX connector
Magnetic encoder : non-touch magnetic rotation encoder ,
        100% correct position memory
RDM : RDM signal two-way transmission
Safety Devices : Over current and overheat protection


Appearance Parameters

Outlooking : Metal base and anti-fire plastic
IP rate : IP20
Light size : 338×216×422mm
Box Size : 400×270×495mm
N.W : 10.6kg       G.W : 12.6kg
Flycase Size(4pcs in 1) : 920×580×615mm
N.W : 42.4kg       G.W : 78.8kg
