Description

Light Source / Power System

Voltage : AC100-240V 50/60Hz
Lamp Power : 421W(LIGHT SKY NSL421M USHIO)
Power : 650W
Color temperature(Lamp) : 6900K
Average lifespan : 1500h
Strobe : double strobe structure ,0.5-9 times/second(adjustable)
Dimmer : 0-100% linear adjustment



Color / GOBO / Effects

Color : 1 white color+14 color wheel, quick rainbow effect
Fixed Gobo : 1 blank gobo+11gobo +3 animation range
Prism : 8 prism+16 double prism + prism combination
Focus & lens : high precision groups of agglutination optical lens
Beam angle : 2.0°
Frost : adjustable frost angle



Control System

Motor : 12PCS super quiet motor
Control mode : DMX512
Channel : standard 16CH, simple 14CH,16PLUS



Other functions

IP address : built-in long-lifed battery which no need electricity
         connected when set IP address
USB intelligent upgrade system : through USB can upgrade software
         system by each and by group (in the same DMX cable)
Other functions : remote control lamp switch, fan’s speed 100W
         power would lower automatically under full shutter condition.
Safety system : built-in over-current and overheat protection system,
         automatically interrupt lamp power when the heating or cooling
         system failure.
Cooling system : adopt axial flow fan which can intelligent adjust
         speed and abstract heat according to the environment.
Outlooking : adopt anti-aging and anti-fire plastic cover, high
         strength alloy cold pressing molding core material



Appearance Parameters

IP rate : IP20 protection
Light Size : 380X300X591mm
N.W : 20.8 Kg
A single carton size : 445X365X670mm
N.W/G.W : 20.8 Kg/24.2Kg
2Pcs to a Flycase : 820X535X800mm
N.W/G.W : 41.6Kg/77.8Kg
