Description

Light Source / Power System

Voltage : AC198-264V ,50-60HZ
Power : 2000W, power factor PF ≥0.98
Lamp : OSRAM lok-it HTI 1700PS
Life Span : 750H
Ballast : Electrical Ballast
Reflector : Double Reflector Cup design,German optical coating process
Lens : φ200mm Diameter,
Luminous Flux Output : 37000LM



Color / GOBO / Effects

Zoom Range : 4-45 degrees
CRI : ≥90
Color Wheel : 8 colour + white,bidirectional rotation rainbow effect
Color Temperature : 2700K-6500K linear adjustment,Linear CTO adjustment
Framing Shutter system : 4facet& 4 blades framing shutters modules, framing shutter system can be rotated by 90 degrees
Iris : 5-100% linear adjustment aperture, with macro function, the speed is adjustable.
Frost : 1 degrees and 20 degrees, can be combined
Dimming : 16 bit, 0-100% linear dimming
Strobe : 1-9 hz synchronization, pulse, random



Control System

Pan/Tilt : Pan/Tilt : 540/270 degrees
Pan/Tilt Fine : 2.11 / 1.05 degrees
Pan/Tilt speed : 2.5 S / 1.5 s
Control protocol : DMX512, RDM, Art-net, wireless DMX512(optional)
Control Channel : Standard25CH
Display : 2.8 inch color LCD,English/Chinese two version language
Working Mode : Silent , Standard, High brightness three modes
Intelligent control : Display board can record device’s using time , show device’s temperature, channel data and software version .
Temperature control : Intelligent temperature control, can automatically adjust the speed of the cooling fan and overheat protection



Other functions

Error alarm : Automatic alarming for fixture error
DMX Address Setting : built-in long-life battery, can set address without power connection
Software upgrade : upgrade via USB interface
Lamp control : Remote Control Lamp switch On/Off, automatically reduce the lamp power when the Shutter is ON



Appearance Parameters

Outlooking : plastic cover parts are made of engineering plastic PA66 + GF, with fire-proof, noise reduction, impact resistance, high temperature resistance, anti-aging characteristics;
IP rate : IP22
Light Size : 503x324x878 mm
A single carton size : 960x570x395mm
N.W : 41 kg      G.W : 46 kg
Flight Case : 765x610x970 mm
N.W : 41 kg      G.W : 85.5 kg
