Light Source / Power System

Voltage : AC100V~240V    50/60Hz
Power : 302W
Lamp : SIRIUS HRI 230W VS60
E-ballast : OSRAM E-ballast
Lamp life span : 1500h
Lamp Temperature : 8000K
Color Temperature : 2500K、3200K、8000K(Optional)

Color / GOBO / Effects

Color wheel : 14 color + white
Fixed gobo wheel : 11+1+animation range.
Prism : 16 facet + 32 facet(standard); 3facet + 8 facet (Option)
Beam angle : 2°
Frost : 45°(standard), 6°(optional)
Focus : linear electronic focus
Dimmer : super smooth dimmer
Strobe : Independent strobe, 0.5 to 20 times / seconds

Control System

Pan/Tilt speed : Pan: 2.9 seconds/540 degree, Tilt: 1.5 seconds/240 degree
Control : DMX512
Channel : 15CH

Other functions

Other feature : display board has record function, which can record lamp using time ,fan’s speed100W power would lower automatically under full shutter condition

Appearance Parameters

Outlooking : Independent shape design PA66 plastic material, Anti UV, anti-aging, high temperature resistance
IP rate : IP44
Light Size : 390x300x602(mm)
Carton Size : 450x430x750(mm)
N.W : 23Kg G.W : 29.5Kg
Fly case size : 940x635x845 (mm) 2pcs in 1
N.W : 46Kg G.W : 96Kg
