Light Source / Power System

Voltage : AC100-240V, 50/60Hz
Power : 507W PF0.96
DMX/RDM Connections : IP66 XLR In/Out (3 pin or 5 pin)
Power Connections : IP66 Power In/Out
LED Chip : LUMILEDS 36pcs×15W RGBL（Red 、Green 、Blue 、Lime）LED
Lifespan : 30000h
LED Chip Lumen : 20758lm
Total Lumen : 17921lm

Color / GOBO / Effects

Lens angle : 6°
Lens material : PMMA
Beam angle : 14°(standard),25°/45°(option)
Installation working angle : ±90°
Color Temperature : 2500K-7000K
CRI : Ra≥75
Color mixing : RGBL macro color system.
Strobe : 1-30Hz electronic strobe and random strobe.
Dimming : 16Bit,0-100% linear dimming,
provides four dimming options

Control System

Control Mode : DMX512,RDM,Stand-mode,Wireless DMX512(Option ）
DMX Channels : 8channel (standard) 1/3/4/5/7/16/20/24CH option
Display : OLED display screen.With Chinese and English two version language.
Intelligent temperature control : Display board can record
device’s using time , show device’s temperature,
channel data and software version .
Software upgrade : Upgrade via DMX connector

Other functions

RDM : RDM signal two-way transmission
Maximum DMX connection qty : 25 pcs.
Thermal Dissipation : Passive ( fanless )
Ambient temperature : -40～ +45℃

Appearance Parameters

Housing : Die-cast Aluminum alloy housing
Housing color : Gray-green color , anti-saline
IP rate : IP66
Light size : 916x275x397mm
N.W : 31.5Kg
Packing : Wooden box Packing
Dimensions : 1000x370x390 mm
N.W : 31.5kg     G.W : 44 kg
Packing : fly case packing
Packing dimensions : 1025x360x525mm
N.W : 31.5kg     G.W : 52.9kg
