Description

Light Source / Power System

Voltage : AC100-240V 50/60Hz
Power : 216W,PF 0.986
Power in connector : Neutrik power
DMX and RDM data in/out : Locking 3-pin
Source : White light LED module
Light source power : 120W
Average life : 20000 h
Luminous Flux : 5200 lm
Light source CCT : 8500 K
CCT Light output : 6000 K
Focus and Lens : High precision optical lens



Color / GOBO / Effects

Color : 14 colors + white,Bi-direction rotation and rainbow effect
Gobo : φ106 11Gobo + 1 white + 3 animation range
Strobe : Double lens strobe(0.5-25 times/second)
Dimmer : 0-100% linear adjustment.
Beam range : 2°( 0.7° / 1.3° beam angle selection )
Output lens diameter : φ135 mm
Light output : 35390 lux @10m
Prism : 8 Prism+16 double Prism+multi combination effect



Control System

Motors : 12 ultra-quiet motors
Control Mode : DMX512 、RDM
Channels : 14CH、16CH 、16Plus
X/Y Travel : 540°/270°
X/Y Resolution : 2.11°/1.05°
X/Y Speed : 2.7S/1.6S
Wash effect : Adjustable wash effect angle
X axis and Y axis : 540°/270°



Other functions

Display : The display panel adopts a 1.77-inch TFT screen
Features : Remote control light swith function display light and lamp’s using time.auto maticallay adjust cooling-fan’s speed,Drop power when strobe lens.
IP Rate : IP20
Safety Devices : BIPOlar circuit breaker with thermal protection;Automatic break in power supply in case of overheating or failed operation of cooling system.
Cooling : Forced ventilation with axial fans.



Appearance Parameters

Structure : Heat-proof plastic+module pressing alloy materials.
Light size : 380X280X480.5(mm)
Box Size : 400X345X570(mm)
N.W : 17.8Kg ,      G.W : 20.3Kg
Flycase Size( 2pcs) : 885X490X740(mm)
N.W : 35.6Kg ,     G.W : 69.8Kg
